Cylinder Bed Overlock Machine for Attaching Elastic TapeAZ8451 class

Numbering on Models


  1. Symbol of series
  2. Class No.: 84 = Cylinder bed overlock
  3. Submodel: 00 = 1 needle machine for blind hemming & general seaming, fitted with hemming guide,  03 = 1needle machine for general seaming,  20 = 2 needle machine for general seaming,  51 = 1 needle machine for attaching elastic tape,  71 = 2 needle machine for attaching elastic tape
  4. Needle distance: O = 1 needle,  Y = 2.4 mm
  5. Overedge seam width: 3 = 3 mm,  4 = 4 mm,  5 = 5 mm
  6. Feeding mode: D = Differential feed
  7. Type of upper knife: F = Flat knife
  8. Applicable tape width: 10 = 23 mm to 40 mm
  9. Device: K2 = Automatic thread chain cutter (vertical type)
  10. Controller: MA = Multi programmable controller, including tape dispenser driver

Specifications

Model) Number of Needles) Number of Threads) Needle distance) Over-edge seam width) Stitch length) Differential ratio) Pressor foot lift) Needle stroke) Machine SpeedRemarks

AZ8451/K2/MA

1 Needle 3 Thread Cylinder Bed Overlock Machine for Attaching Elastic Tape, Fitted with Stepping Motor Driven Elastic Metering Device with Tape Cutter (Tape Width: 6 mm - 12 mm)		13-3, 4, 51.0 - 3.51:0.8 - 1:2.0624.56,500Tape Width: 6 mm - 12 mm

AZ8451-10/K2/MA

1 Needle 3 Thread Cylinder Bed Overlock Machine for Attaching Elastic Tape, Fitted with Stepping Motor Driven Elastic Metering Device with Tape Cutter (Tape Width: 23 mm - 40 mm)		13-3, 4, 51.0 - 3.51:0.8 - 1:2.0624.55,000Tape Width: 23 mm - 40 mm

AZ8452L

1 Needle 3 Thread Cylinder Bed Overlock Machine for Attaching Elastic Tape, Fitted with Stepping Motor Driven Elastic Metering Device (without Cutter)		13-4, 51.0 - 3.51:0.8 - 1:2.0624.56,500Tape Width: 6 mm - 12 mm

AZ8471/K2/MA

2 Needle 4 Thread Cylinder Bed Overlock Machine for Attaching Elastic Tape, Fitted with Stepping Motor Driven Elastic Metering Device with Tape Cutter (Tape Width: 6 mm - 12 mm)		2425, 61.0 - 3.51:0.8 - 1:2.0624.56,500Tape Width: 6 mm - 12 mm

AZ8471-10/K2/MA

2 Needle 4 Thread Cylinder Bed Overlock Machine for Attaching Elastic Tape, Fitted with Stepping Motor Driven Elastic Metering Device with Tape Cutter (Tape Width: 23 mm - 40 mm)		242.45, 61.0 - 3.51:0.8 - 1:2.0624.55,000Tape Width: 23 mm - 40 mm
